关于RDPY
RDPY是一款功能强大的RDP远程桌面协议实现工具，该工具基于纯Python开发，并提供了完整的客户端和服务器端应用程序。
RDPY基于事件驱动的网络引擎Twisted构建，RDPY支持标准RDP安全层、RDP over SSL和NLA认证（通过ntlmv2认证协议）。
RDPY提供了下列RDP和VNC代码：
1、RDP中间人代理（用于记录会话）；
2、RDP蜜罐；
3、RDP截图工具；
4、RDP客户端；
5、VNC客户端；
6、VNC截图工具；
7、RSS Player；
工具下载
由于该工具基于Python开发，因此我们首先需要在本地设备上安装并配置好Python环境。
接下来，广大研究人员可以使用下列命令将该项目源码克隆至本地：
git clone https://github.com/citronneur/rdpy.git
需要注意的是，该工具所实现的bitmap解压缩算法考虑到性能问题，所以使用了C代码实现。
代码构建
该工具所使用的pyqt4需要用到下列依赖组件：
rdpy-rdpclient
rdpy-rdpscreenshot
rdpy-vncclient
rdpy-vncscreenshot
rdpy-rssplayer
Linux：
sudo apt-get install python-qt4
macOS：
$ brew install qt sip pyqt
Windows：
|
x86 |
x86_64 |
构建命令如下：
$ git clone https://github.com/citronneur/rdpy.git rdpy $ pip install twisted pyopenssl qt4reactor service_identity rsa pyasn1 $ python rdpy/setup.py install
或使用pip命令构建：
$ pip install rdpy
如需使用Virtualenv，你还需要链接qt4库：
$ ln -s /usr/lib/python2.7/dist-packages/PyQt4/ $VIRTUAL_ENV/lib/python2.7/site-packages/ $ ln -s /usr/lib/python2.7/dist-packages/sip.so $VIRTUAL_ENV/lib/python2.7/site-packages/
工具使用
RDPY提供了一些非常有用的代码库，这些代码库适用于Linux和Windows操作系统。
rdpy-rdpclient
rdpy-rdpclient是一个简单的RDP Qt4客户端：
$ rdpy-rdpclient.py [-u username] [-p password] [-d domain] [-r rss_ouput_file] [...] XXX.XXX.XXX.XXX[:3389]
rdpy-vncclient
rdpy-vncclient是一个VNC Qt4客户端：
$ rdpy-vncclient.py [-p password] XXX.XXX.XXX.XXX[:5900]
rdpy-rdpscreenshot
rdpy-rdpscreenshot可以将登录屏幕截图保存到文件中：
$ rdpy-rdpscreenshot.py [-w width] [-l height] [-o output_file_path] XXX.XXX.XXX.XXX[:3389]
rdpy-vncscreenshot
rdpy-vncscreenshot可以将第一个界面保存到文件中：
$ rdpy-vncscreenshot.py [-p password] [-o output_file_path] XXX.XXX.XXX.XXX[:5900]
rdpy-rdpmitm
rdpy-rdpmitm是一个RDP代理，允许我们针对RDP协议执行中间人攻击：
$ rdpy-rdpmitm.py -o output_dir [-l listen_port] [-k private_key_file_path] [-c certificate_file_path] [-r (for XP or server 2003 client)] target_host[:target_port]
rdpy-rdphoneypot
rdpy-rdphoneypot是一个RDP蜜罐，可以在记录会话场景（RSS）中通过RDP协议重放攻击场景：
$ rdpy-rdphoneypot.py [-l listen_port] [-k private_key_file_path] [-c certificate_file_path] rss_file_path_1 ... rss_file_path_N
rdpy-rssplayer
rdpy-rssplayer用于重放rdpy-rdpmitm或rdpy-rdpclient生成的RSS文件：
$ rdpy-rssplayer.py rss_file_path
独立RDPY库
我们还可以将该项目以一个独立协议代码库（+网络引擎Twisted）来使用。
RDP客户端
from rdpy.protocol.rdp import rdp
class MyRDPFactory(rdp.ClientFactory):
def clientConnectionLost(self, connector, reason):
reactor.stop()
def clientConnectionFailed(self, connector, reason):
reactor.stop()
def buildObserver(self, controller, addr):
class MyObserver(rdp.RDPClientObserver):
def onReady(self):
"""
@summary: Call when stack is ready
"""
#send 'r' key
self._controller.sendKeyEventUnicode(ord(unicode("r".toUtf8(), encoding="UTF-8")), True)
#mouse move and click at pixel 200x200
self._controller.sendPointerEvent(200, 200, 1, true)
def onUpdate(self, destLeft, destTop, destRight, destBottom, width, height, bitsPerPixel, isCompress, data):
"""
@summary: Notify bitmap update
@param destLeft: xmin position
@param destTop: ymin position
@param destRight: xmax position because RDP can send bitmap with padding
@param destBottom: ymax position because RDP can send bitmap with padding
@param width: width of bitmap
@param height: height of bitmap
@param bitsPerPixel: number of bit per pixel
@param isCompress: use RLE compression
@param data: bitmap data
"""
def onSessionReady(self):
"""
@summary: Windows session is ready
"""
def onClose(self):
"""
@summary: Call when stack is close
"""
return MyObserver(controller)
from twisted.internet import reactor
reactor.connectTCP("XXX.XXX.XXX.XXX", 3389, MyRDPFactory())
reactor.run()
RDP服务器
from rdpy.protocol.rdp import rdp class MyRDPFactory(rdp.ServerFactory): def buildObserver(self, controller, addr): class MyObserver(rdp.RDPServerObserver): def onReady(self): """ @summary: Call when server is ready to send and receive messages """ def onKeyEventScancode(self, code, isPressed): """ @summary: Event call when a keyboard event is catch in scan code format @param code: scan code of key @param isPressed: True if key is down @see: rdp.RDPServerObserver.onKeyEventScancode """ def onKeyEventUnicode(self, code, isPressed): """ @summary: Event call when a keyboard event is catch in unicode format @param code: unicode of key @param isPressed: True if key is down @see: rdp.RDPServerObserver.onKeyEventUnicode """ def onPointerEvent(self, x, y, button, isPressed): """ @summary: Event call on mouse event @param x: x position @param y: y position @param button: 1, 2, 3, 4 or 5 button @param isPressed: True if mouse button is pressed @see: rdp.RDPServerObserver.onPointerEvent """ def onClose(self): """ @summary: Call when human client close connection @see: rdp.RDPServerObserver.onClose """ return MyObserver(controller) from twisted.internet import reactor reactor.listenTCP(3389, MyRDPFactory()) reactor.run()
VNC客户端
from rdpy.protocol.rfb import rfb
class MyRFBFactory(rfb.ClientFactory):
def clientConnectionLost(self, connector, reason):
reactor.stop()
def clientConnectionFailed(self, connector, reason):
reactor.stop()
def buildObserver(self, controller, addr):
class MyObserver(rfb.RFBClientObserver):
def onReady(self):
"""
@summary: Event when network stack is ready to receive or send event
"""
def onUpdate(self, width, height, x, y, pixelFormat, encoding, data):
"""
@summary: Implement RFBClientObserver interface
@param width: width of new image
@param height: height of new image
@param x: x position of new image
@param y: y position of new image
@param pixelFormat: pixefFormat structure in rfb.message.PixelFormat
@param encoding: encoding type rfb.message.Encoding
@param data: image data in accordance with pixel format and encoding
"""
def onCutText(self, text):
"""
@summary: event when server send cut text event
@param text: text received
"""
def onBell(self):
"""
@summary: event when server send biiip
"""
def onClose(self):
"""
@summary: Call when stack is close
"""
return MyObserver(controller)
from twisted.internet import reactor
reactor.connectTCP("XXX.XXX.XXX.XXX", 3389, MyRFBFactory())
reactor.run()
许可证协议
本项目的开发与发布遵循GPL-3.0开源许可证协议。
项目地址
RDPY：【GitHub传送门】
参考资料
http://sourceforge.net/projects/pyqt/files/PyQt4/PyQt-4.11.3/PyQt4-4.11.3-gpl-Py2.7-Qt4.8.6-x32.exe
